Model
Year
MG
SG
Illustration
Restrictions
UPD
PET
928
1995
0
01
001-00
248
|
Model |
Year |
MG |
SG |
Illustration |
Restrictions |
UPD |
|
PET |
|
|
928 |
1995 |
0 |
01 |
001-00 |
248 |
||||
|
|
|
 |
Pos |
Part Number |
Description |
Remark |
Qty |
Model |
|
|
|
rear window wiper |
|
|
|
|
|
1 |
928 628 071 03 |
engine bracket (with bearing) |
|
|
|
|
|
2 |
928 628 202 02 |
joint rod |
|
|
|
|
|
3 |
928 628 403 02 |
wiper motor |
|
|
|
|
|
4 |
928 628 309 03 |
wiper bearing |
|
|
|
|
|
4A |
N 012 007 02 |
lock ring (A6) |
|
|
|
|
|
4B |
900 075 057 02 |
hexagon-head bolt |
|
|
|
|
|
5 |
928 628 325 01 |
bush |
|
|
|
|
|
6 |
928 628 326 01 |
bush |
|
|
|
|
|
7 |
928 628 610 05 |
wiper arm |
|
|
|
|
|
8 |
A 928 628 218 01 |
wiper blade |
|
|
|
|
|
8 |
928 628 218 02 |
wiper blade |
|
|
|
|
|
9 |
803 955 437 |
washer (B8) |
|
|
|
|
|
10 |
N Oll 524 7 |
washer (6,4) |
|
|
|
|
|
11 |
900 076 025 02 |
hexagon nut (M8) |
|
|
|
|
|
12 |
900 076 010 02 |
hexagon nut (M6) |
|
|
|
|
|
13 |
900 075 338 02 |
hexagon-head bolt (M6*25) |
|
|
|
|
|
14 |
N 011 524 7 |
washer (6,4*14) |
|
|
|
|
|
15 |
N 011 666 7 |
washer (6,4) |
|
|
|
|
|
16 |
900 910 010 09 |
lock nut (VM6) |
|
|
|
|
|
17 |
928 628 621 00 |
cap (guiding rod) |
|
|
|
|
|
17 |
928 628 622 00 |
cap (wiper arm) |
|
|
|
|
|
|
|
relay for rear window wiper (see group 9/03/10) |
|
|
|
|
|
19 |
928 628 287 00 |
grommet |
|
3 |
|
